Stage 2 Lift Kit w/Shocks; 3.5 in. Lift; Incl. Track Bar; Front Driveshaft; Lower Ctrl Arms w/Brackets; Swaybar Links; Coil Springs; Bump Stop; Front and Rear Premium N3 Shocks;
Application Summary:
| Year |
Make/Model |
| 2018-2023 |
Jeep Wrangler |
| Attributes |
| California Proposition 65 |
WARNING: Cancer - www.P65Warnings.ca.gov |
| Category |
Susp Lift Kits 4wd |
| Country of Origin (Primary) |
CN |
| Front Components |
Adjustable Track Bar, CV Dana 30 Front Driveshaft, Adjustable Lower Control Arms, Side Control Arm Drop Brackets, Lifted Coil Springs, Sway Bar Links, Bump Stops |
| Front Kit Componenets |
Adjustable Track Bar, CV Dana 30 Front Driveshaft, Adjustable Lower Control Arms, Side Control Arm Drop Brackets, Lifted Coil Springs, Sway Bar Links, Bump Stops |
| Front Kit Components |
Adjustable Track Bar, CV Dana 30 Front Driveshaft, Adjustable Lower Control Arms, Side Control Arm Drop Brackets, Lifted Coil Springs, Sway Bar Links, Bump Stops |
| GTIN |
00843030148751 |
| Harmonized Tariff Code (Schedule B) |
8708809900 |
| Hazardous Material Code |
N |
| Install Time |
4-6 hours |
| Life Cycle Status Code |
Available to Order |
| Lift/Drop Height |
3.5 in. |
| NAFTA Preference Criterion Code |
B |
| Rear Components |
Lifted Coil Springs, Sway Bar Links, Track Bar Bracket, Bump Stops |
| Rear Kit Components |
Lifted Coil Springs, Sway Bar Links, Track Bar Bracket, Bump Stops |
| SDR Required Flag |
N |
| Shipping Options |
No Restrictions |
| Ships in Multiple Boxes |
Y |
| Tire & Wheel Size Combinations |
35x12.50 R20 - 20x10, Offset: -18mm, 35x12.50 R20 - 20x10, Offset: -18mm |
| Tire, Wheel, and Offset Info |
35x12.50R17:17x8.5:5x5.0:+0:-; 35x12.50R17:17x8.5:5x5.0:+1:-; 35x12.50R17:17x9:5x5.0:-12:-; 35x12.50R17:17x9:5x5.0:+0:-; 35x12.50R17:17x9:5x5.0:+1:-; 35x12.50R18:18x8.5:5x5.0:+0:-; 35x12.50R18:18x8.5:5x5.0:+1:-; 35x12.50R18:18x9:5x5.0:+0:-; 35x12.50R18:18x9:5x5.0:+1:-; 35x12.50R18:18x10:5x5.0:-25:-; 35x12.50R18:18x10:5x5.0:-24:-; 35x12.50R18:18x10:5x5.0:-19:-; 35x12.50R18:18x10:5x5.0:-18:-; 35x12.50R20:20x9:5x5.0:-12:-; 295 60R20:20x9:5x5.0:-12:-; 35x12.50R20:20x9:5x5.0:+0:-; 35x12.50R20:20x9:5x5.0:+1:-; 295 60R20:20x9:5x5.0:+1:-; 35x12.50R20:20x10:5x5.0:-25:-; 35x12.50R20:20x10:5x5.0:-24:-; 35x12.50R20:20x10:5x5.0:-19:-; 295 60R20:20x10:5x5.0:-19:-; 35x12.50R20:20x10:5x5.0:-18:-; 295 60R20:20x10:5x5.0:-18:-; 35x12.50R22:22x10:5x5.0:-25:-; 35x12.50R22:22x10:5x5.0:-24:-; 35x12.50R22:22x10:5x5.0:-19:-; 35x12.50R22:22x10:5x5.0:-18:- |
