4 Inch Lift Kit - Ford F-150 2WD (1980-1996)
Boosts Off-Road Performance. If you want to add a little more attitude to your Ford F-150, then Rough Country's 4-Inch Lift Kit is just what you need. This kit has everything you need to raise the front of your vehicle to equal height with the rear, giving you a leveled, flush look. With this lift kit, you'll also get a better ride height and a more aggressive appearance. Plus, it's designed to fit up to a 33" tire with proper wheel backspacing. So go ahead and add some attitude to your truck - Rough Country's 4-Inch Lift Kit will take it to new heights. High-Quality Construction. This lift kit has been designed with a set of front, durable coil springs allowing you to gain additional ride height without sacrificing quality. A set of radius arms and axle drop brackets are provided for keeping everything at optimum angles so that even after lifting, your truck will still maintain the factory-like ride! Rough Country's premium N3 shocks are also included, engineered to provide a smooth and comfortable ride on- or off-road. These 10-stage variable high-pressure Nitrogen charged shocks have an 18mm spring-loaded piston rod and a 54mm shock body that allows for faster cooling. Installation and Warranty. Rough Country's 4-inch lift kit includes free shipping and all the installation components. In addition, our products are backed with a limited lifetime replacement warranty. This means that you have the security of knowing that Rough Country's products will work as they should, even after years of use!
- Increased ground clearance
- Levels the front with the rear of the vehicle
Information:
Extended brake lines are recommended. If vehicle is equipped with a front sway-bar, drop brackets are recommended. (#1018)
Application Summary:
| Year |
Make/Model |
| 1980-1996 |
Ford F-150 |
| Attributes |
| California Proposition 65 |
WARNING: Cancer - www.P65Warnings.ca.gov |
| Category |
Susp Lift Kits 2wd |
| Country of Origin (Primary) |
US |
| Front Components |
Lifted coil springs Radius arm drop brackets I-beam drop brackets Power steering pitman arm FREE steering stabilizer Hardware, Lifted coil springs Radius arm drop brackets I-beam drop brackets Power steering pitman arm FREE steering stabilizer Hardware |
| Front Kit Componenets |
Lifted coil springs, Radius arm drop brackets, I-beam drop brackets, Power steering pitman arm, FREE steering stabilizer, Hardware |
| Front Kit Components |
Lifted coil springs, Radius arm drop brackets, I-beam drop brackets, Power steering pitman arm, FREE steering stabilizer, Hardware |
| GTIN |
00843030127138 |
| Harmonized Tariff Code (Schedule B) |
8708809900 |
| Hazardous Material Code |
N |
| Install Time |
6-8 hours, 6-8 hours |
| Life Cycle Status Code |
Available to Order |
| Lift/Drop Height |
4 in. |
| NAFTA Preference Criterion Code |
B |
| Rear Components |
3 in. lift blocks U-bolts Hardware, 3 inch lift blocks U-bolts Hardware |
| Rear Kit Components |
3in lift blocks, U-bolts, Hardware |
| SDR Required Flag |
N |
| Shipping Options |
No Restrictions |
| Ships in Multiple Boxes |
Y |
| Tire Info |
33x12.50R15:15x8:5x5.5:-19:-;33x12.50R15:15x8:5x5.5:-18:-;33x12.50R15:15x10:5x5.5:-39:Trimming Required;33x12.50R16:16x8:5x5.5:-19:-;33x12.50R16:16x8:5x5.5:-18:-;33x12.50R16:16x10:5x5.5:-39:Trimming Required;33x12.50R17:17x8.5:5x5.5:+0:-;33x12.50R17:17x8.5:5x5.5:+1:-;33x12.50R17:17x9:5x5.5:-12:-;33x12.50R17:17x9:5x5.5:+0:-;285/70R17:17x9:5x5.5:+0:-;33x12.50R17:17x9:5x5.5:+1:-;285/70R17:17x9:5x5.5:+1:-;33x12.50R18:18x8.5:5x5.5:+0:-;33x12.50R18:18x8.5:5x5.5:+1:-;33x12.50R18:18x9:5x5.5:-12:-;305/60R18:18x9:5x5.5:-12:-;285/65R18:18x9:5x5.5:-12:-;275/65R18:18x9:5x5.5:-12:-;33x12.50R18:18x9:5x5.5:+0:-;305/60R18:18x9:5x5.5:+0:-;285/65R18:18x9:5x5.5:+0:-;275/65R18:18x9:5x5.5:+0:-;33x12.50R18:18x9:5x5.5:+1:-;305/60R18:18x9:5x5.5:+1:-;285/65R18:18x9:5x5.5:+1:-;275/65R18:18x9:5x5.5:+1:-;33x12.50R18:18x10:5x5.5:-25:-;33x12.50R18:18x10:5x5.5:-19:-;33x12.50R18:18x10:5x5.5:-18:-;33x12.50R20:20x9:5x5.5:-12:-;33x12.50R20:20x9:5x5.5:+0:-;305/55R20:20x9:5x5.5:+0:-;285/55R20:20x9:5x5.5:+0:-;33x12.50R20:20x9:5x5.5:+1:-;305/55R20:20x9:5x5.5:+1:-;285/55R20:20x9:5x5.5:+1:-;33x12.50R20:20x10:5x5.5:-25:Minor Trimming;33x12.50R20:20x10:5x5.5:-19:Minor Trimming;305/55R20:20x10:5x5.5:-19:Minor Trimming;285/55R20:20x10:5x5.5:-19:Minor Trimming;33x12.50R20:20x10:5x5.5:-18:Minor Trimming;305/55R20:20x10:5x5.5:-18:Minor Trimming;285/55R20:20x10:5x5.5:-18:Minor Trimming;33x12.50R22:22x10:5x5.5:-25:Minor Trimming;33x12.50R22:22x10:5x5.5:-19:Minor Trimming;305/45R22:22x10:5x5.5:-19:-;33x12.50R22:22x10:5x5.5:-18:Minor Trimming;305/45R22:22x10:5x5.5:-18:-;33x12.50R22:22x12:5x5.5:-44:Trimming Required |
| Tire, Wheel, and Offset Info |
33x12.50R15:15x8:5x5.5:-19:-; 33x12.50R15:15x10:5x5.5:-25:-; 33x12.50R15:15x10:5x5.5:-24:-; 33x12.50R15:15x10:5x5.5:-19:-; 33x12.50R15:15x10:5x5.5:-18:-; 33x12.50R16:16x8:5x5.5:-19:-; 33x12.50R16:16x10:5x5.5:-25:-; 33x12.50R16:16x10:5x5.5:-24:-; 33x12.50R16:16x10:5x5.5:-19:-; 33x12.50R16:16x10:5x5.5:-18:-; 33x12.50R17:17x8.5:5x5.5:+0:-; 33x12.50R17:17x8.5:5x5.5:+1:-; 33x12.50R17:17x9:5x5.5:-12:-; 33x12.50R17:17x9:5x5.5:+0:-; 33x12.50R17:17x9:5x5.5:+1:-; 33x12.50R18:18x8.5:5x5.5:+0:-; 33x12.50R18:18x8.5:5x5.5:+1:-; 33x12.50R18:18x9:5x5.5:-12:-; 33x12.50R18:18x9:5x5.5:+0:-; 285 65R18:18x9:5x5.5:+0:-; 33x12.50R18:18x9:5x5.5:+1:-; 285 65R18:18x9:5x5.5:+1:-; 33x12.50R18:18x10:5x5.5:-25:-; 33x12.50R18:18x10:5x5.5:-24:-; 33x12.50R18:18x10:5x5.5:-19:-; 33x12.50R18:18x10:5x5.5:-18:-; 33x12.50R20:20x9:5x5.5:-12:-; 33x12.50R20:20x9:5x5.5:+0:-; 305 55R20:20x9:5x5.5:+0:-; 285 55R20:20x9:5x5.5:+0:-; 33x12.50R20:20x9:5x5.5:+1:-; 305 55R20:20x9:5x5.5:+1:-; 285 55R20:20x9:5x5.5:+1:-; 33x12.50R20:20x10:5x5.5:-25:-; 33x12.50R20:20x10:5x5.5:-24:-; 33x12.50R20:20x10:5x5.5:-19:-; 305 55R20:20x10:5x5.5:-19:-; 285 55R20:20x10:5x5.5:-19:-; 33x12.50R20:20x10:5x5.5:-18:-; 33x12.50R22:22x10:5x5.5:-25:-; 33x12.50R22:22x10:5x5.5:-24:-; 33x12.50R22:22x10:5x5.5:-19:-; 33x12.50R22:22x10:5x5.5:-18:- |
