5 Inch Lift Kit - N3 Strut - Chevy/GMC 1500 4WD (07-13)
Bold Stance, Superior Performance: Take your Chevy/GMC 1500 to the next level with Rough Country's 5-Inch Suspension Lift Kit. This kit delivers the aggressive, leveled look you want-while preserving your factory ride quality. Run up to 33-inch tires on your stock 20-inch wheels and enjoy a high-clearance crossmember design that dramatically increases ground clearance for confident off-road capability. Engineered for Strength and Precision: Built with 100% laser-cut materials using state-of-the-art CAD technology, this kit ensures a perfect fit and long-lasting durability. The 5-inch lifted knuckle design maintains proper geometry for a smooth, factory-like ride. Durable fabricated rear blocks offer greater strength and longevity than cast alternatives, while eliminating common lift block issues. Premium Shock Performance: Included N3 Series shock absorbers are application-valved for your truck, delivering a well-balanced ride both on and off the road. Want even more performance? Upgrade to N3 loaded struts for better ride quality, quicker installation, and enhanced suspension response without the use of spacers. Hassle-Free Installation and Backed by Warranty: This all-in-one kit includes everything needed for a smooth install, along with clear instructions for the DIY enthusiast. And with Rough Country's Limited Lifetime Warranty, you get peace of mind that your lift kit is built to perform for the long haul.
- Fits 33-Inch Tires with Factory 20-Inch Wheels: Run larger tires without replacing your stock wheels for a bold, capable stance.
- Achieves a Level Stance: Eliminates factory rake for a clean, aggressive profile that enhances both form and function.
- High-Clearance Crossmember Design: Maximizes ground clearance for superior off-road performance and obstacle navigation.
- Precision Laser-Cut Components: Crafted using advanced CAD technology for a perfect fit and uncompromising durability.
- Heavy-Duty Fabricated Blocks: Engineered to outlast cast alternatives with superior strength and long-term reliability.
- N3 Series Shock Absorbers Included: Application-specific valving delivers the ideal balance of comfort and control on any terrain.
- Optional N3 Loaded Struts Upgrade: Upgrade from traditional spacers to N3 loaded struts for improved ride quality, simplified installation, and enhanced suspension performance.
Information:
Requires minor cutting and drilling. Does NOT fit 2007 "Classic" models. For a visual, please click here. Due to vibration issues after lifting, AWD models require a new aftermarket driveshaft SKU: 5083.1. 18" or larger wheels are required to ensure proper clearance of the supplied knuckles.
Application Summary:
| Year |
Make/Model |
| 2007-2013 |
Chevrolet Silverado 1500 |
| 2010 |
GMC Sierra |
| 2013 |
GMC Sierra |
| 2007-2013 |
GMC Sierra 1500 |
| Attributes |
| California Proposition 65 |
WARNING: Cancer - www.P65Warnings.ca.gov |
| Category |
Susp Lift Kits 4wd, Susp Lift Kits 4wd |
| Country of Origin (Primary) |
US |
| Front Components |
Lifted knuckles, Front crossmember, Rear crossmember, Brake line brackets, CV spacers, Differential drop brackets, Differential skid plate, Sway-bar drop brackets, Hardware |
| Front Kit Componenets |
Lifted knuckles, Front crossmember, Rear crossmember, Brake line brackets, CV spacers, Differential drop brackets, Differential skid plate, Sway-bar drop brackets, Hardware |
| Front Kit Components |
Lifted knuckles, Front crossmember, Rear crossmember, Brake line brackets, CV spacers, Differential drop brackets, Differential skid plate, Sway-bar drop brackets, Hardware |
| GTIN |
00843030170424 |
| Harmonized Tariff Code (Schedule B) |
8708801600 |
| Hazardous Material Code |
N |
| Install Time |
8-10 hours |
| Life Cycle Status Code |
Available to Order |
| Lift/Drop Height |
5 in. |
| NAFTA Preference Criterion Code |
B |
| Rear Components |
4.5in fabricated lift blocks, U-bolts, Hardware |
| Rear Kit Components |
4.5in fabricated lift blocks, U-bolts, Hardware |
| SDR Required Flag |
N |
| Shipping Group |
No Restrictions |
| Shipping Options |
No Restrictions |
| Ships in Multiple Boxes |
Y, Y |
| Tire & Wheel Size Combinations |
305/55 R20 - 20x9, Offset: +12 to +18mm (Models equipped with Factory 18-inch or larger wheels must run 18-inch or larger wheels if changing to aftermarket wheels), 305/55 R20 - 20x9, Offset: +12 to +18mm (Models equipped with Factory 18-inch or larger wheels must run 18-inch or larger wheels if changing to aftermarket wheels) |
| Tire, Wheel, and Offset Info |
33x12.50R18:18x8.5:6x5.5:+0:-; 33x12.50R18:18x8.5:6x5.5:+1:-; 33x12.50R18:18x9:6x5.5:+0:-; 285 65R18:18x9:6x5.5:+0:-; 33x12.50R18:18x9:6x5.5:+1:-; 285 65R18:18x9:6x5.5:+1:-; 33x12.50R18:18x9:6x5.5:+12:-; 305 65R18:18x9:6x5.5:+12:-; 33x12.50R18:18x9:6x5.5:+18:-; 305 65R18:18x9:6x5.5:+18:-; 285 65R18:18x9:6x5.5:+18:-; 285 65R18:18x9:6x5.5:+19:-; 285 65R18:18x9:6x5.5:+20:-; 33x12.50R20:20x9:6x5.5:+0:-; 305 55R20:20x9:6x5.5:+0:-; 295 60R20:20x9:6x5.5:+0:Minor Trimming; 33x12.50R20:20x9:6x5.5:+1:-; 305 55R20:20x9:6x5.5:+1:-; 295 60R20:20x9:6x5.5:+1:Minor Trimming; 33x12.50R20:20x9:6x5.5:+12:-; 305 55R20:20x9:6x5.5:+12:-; 33x12.50R20:20x9:6x5.5:+18:-; 305 55R20:20x9:6x5.5:+18:-; 295 60R20:20x9:6x5.5:+18:Minor Trimming; 33x12.50R20:20x9:6x5.5:+20:-; 305 55R20:20x9:6x5.5:+20:-; 295 60R20:20x9:6x5.5:+20:-; 295 60R20:20x10:6x5.5:-19:Trimming Required; 295 60R20:20x10:6x5.5:-18:Trimming Required |
| Utv Product |
N |
