5 Inch Lift Kit - N3 Struts - Chevy/GMC 1500 (07-13)
Includes application valved N3 series shock absorbers which offer the best in balanced performance for on and off-road use
- Can run 33" tires on factory 20" wheels
- Includes pre-loaded coil for no-fuss installation Provides highly sought level stance
- High clearance crossmember design gives unmatched ground clearance
- Requires no modification to the stock drivetrain or exhaust
- 100% precision laser cut materials using the latest computer aided design process
- Re-uses stock front skid plate Includes application valved N3 series shock absorbers which offer the best in balanced performance for on and off-road use.
Information:
Requires minor cutting and drilling. Does NOT fit 2007 "Classic" models. 18" or larger wheels are required. Please view installation instructions for complete information on proper tire/wheel combinations.
Application Summary:
| Year |
Make/Model |
| 2007-2013 |
Chevrolet Silverado 1500 |
| 2007-2013 |
GMC Sierra 1500 |
| Attributes |
| California Proposition 65 |
WARNING: Cancer - www.P65Warnings.ca.gov |
| Category |
Susp Lift Kits 2wd |
| Country of Origin (Primary) |
CN |
| Front Components |
Lifted knuckles, Front crossmember, Rear crossmember, Brake line brackets, Sway-bar drop brackets, Hardware |
| Front Kit Componenets |
Lifted knuckles, Front crossmember, Rear crossmember, Brake line brackets, Sway-bar drop brackets, Hardware |
| Front Kit Components |
Lifted knuckles, Front crossmember, Rear crossmember, Brake line brackets, Sway-bar drop brackets, Hardware |
| GTIN |
00843030184278 |
| Harmonized Tariff Code (Schedule B) |
8708809900 |
| Hazardous Material Code |
N |
| Install Time |
8-10 hours |
| Life Cycle Status Code |
Available to Order |
| Lift/Drop Height |
5 in. |
| NAFTA Preference Criterion Code |
B |
| Rear Components |
4.5in fabricated lift blocks, U-bolts, Hardware |
| Rear Kit Components |
4.5in fabricated lift blocks, U-bolts, Hardware |
| SDR Required Flag |
N |
| Shipping Options |
No Restrictions |
| Ships in Multiple Boxes |
Y |
| Tire & Wheel Size Combinations |
305/55 R20 - 20x9, Offset: +12 to +18mm (Models equipped with Factory 18-inch or larger wheels must run 18-inch or larger wheels if changing to aftermarket wheels), 305/55 R20 - 20x9, Offset: +12 to +18mm (Models equipped with Factory 18-inch or larger wheels must run 18-inch or larger wheels if changing to aftermarket wheels) |
| Tire, Wheel, and Offset Info |
295 55R20:Factory 20:6x5.5:-:0.25 Spacer; 285 65R18:Factory 18:6x5.5:-:-; 305 65R18:18x9:6x5.5:+12:-; 305 65R18:18x9:6x5.5:+18:-; 285 65R18:18x9:6x5.5:+18:-; 285 65R18:18x9:6x5.5:+19:-; 285 65R18:18x9:6x5.5:+20:-; 305 55R20:20x9:6x5.5:+12:-; 305 55R20:20x9:6x5.5:+18:-; 295 60R20:20x9:6x5.5:+18:-; 305 55R20:20x9:6x5.5:+20:-; 295 60R20:20x9:6x5.5:+20:- |
