Suspension Lift Kit; 7 in.; Vertex and V2 Shocks; Beefy Lifted Knuckles; Laser Cut; Front/Rear High Clearance Cross Members; Fabricated Anti-Wrap Lift Block;
Application Summary:
| Year |
Make/Model |
| 2014-2018 |
Chevrolet Silverado 1500 |
| 2019 |
Chevrolet Silverado 1500 LD |
| 2014-2018 |
GMC Sierra 1500 |
| Attributes |
| California Proposition 65 |
WARNING: Cancer - www.P65Warnings.ca.gov |
| Category |
Vertex Kits |
| Country of Origin (Primary) |
TH |
| Front Components |
Lifted knuckles, Front crossmember, Rear crossmember, Lifted Vertex Reservoir Coil-Overs, CV spacers, Differential drop brackets, Differential skid plate, Sway-bar drop brackets, Hardware |
| Front Kit Componenets |
Lifted knuckles, Front crossmember, Rear crossmember, Lifted Vertex Reservoir Coil-Overs, CV spacers, Differential drop brackets, Differential skid plate, Sway-bar drop brackets, Hardware |
| Front Kit Components |
Lifted knuckles, Front crossmember, Rear crossmember, Lifted Vertex Reservoir Coil-Overs, CV spacers, Differential drop brackets, Differential skid plate, Sway-bar drop brackets, Hardware |
| GTIN |
00843030163594 |
| Harmonized Tariff Code (Schedule B) |
8708809900 |
| Hazardous Material Code |
N |
| Install Time |
8-10 hours |
| Life Cycle Status Code |
Available to Order |
| Lift/Drop Height |
7 in. |
| NAFTA Preference Criterion Code |
D |
| Rear Components |
Fabricated lift blocks, Brake line brackets, U-bolts, Hardware |
| Rear Kit Components |
Fabricated lift blocks, Brake line brackets, U-bolts, Hardware |
| SDR Required Flag |
N |
| Shipping Options |
No Restrictions |
| Ships in Multiple Boxes |
Y |
| Tire & Wheel Size Combinations |
315/55 R20 - 20x9, Offset: +12 to +18mm (Models equipped with Factory 18-inch or larger wheels must run 18-inch or larger wheels if changing to aftermarket wheels), 315/55 R20 - 20x9, Offset: +12 to +18mm (Models equipped with Factory 18-inch or larger wheels must run 18-inch or larger wheels if changing to aftermarket wheels) |
| Tire, Wheel, and Offset Info |
35x12.50R20:Factory 20:6x5.5:-:0.25 Spacer; 295 70R18:Factory 18:6x5.5:-:0.25 Spacer; 35x12.50R18:18x8.5:6x5.5:+1:-; 35x12.50R18:18x9:6x5.5:-12:-; 35x12.50R18:18x9:6x5.5:+0:Trimming Required; 35x12.50R18:18x9:6x5.5:+1:-; 35x12.50R20:20x9:6x5.5:-12:-; 295 60R20:20x9:6x5.5:-12:Minor Trimming; 35x12.50R20:20x9:6x5.5:+0:-; 295 60R20:20x9:6x5.5:+0:Minor Trimming; 35x12.50R20:20x9:6x5.5:+1:-; 295 60R20:20x9:6x5.5:+1:Minor Trimming; 35x12.50R20:20x10:6x5.5:-25:Trimming Required; 295 60R20:20x10:6x5.5:-25:Minor Trimming; 35x12.50R20:20x10:6x5.5:-24:Trimming Required; 295 60R20:20x10:6x5.5:-24:Minor Trimming; 35x12.50R20:20x10:6x5.5:-19:Trimming Required; 295 60R20:20x10:6x5.5:-19:Minor Trimming; 35x12.50R20:20x10:6x5.5:-18:Trimming Required; 295 60R20:20x10:6x5.5:-18:Minor Trimming; 35x12.50R22:22x10:6x5.5:-25:Trimming Required; 35x12.50R22:22x10:6x5.5:-24:Trimming Required; 35x12.50R22:22x10:6x5.5:-19:Trimming Required; 35x12.50R22:22x10:6x5.5:-18:Trimming Required |
