Application specific valving to maximize performance.
FOX Performance Series shocks contain the latest in shock technology to transform the performance of your Truck or SUV. They use our race-proven damping control to provide a comfortable on-road ride and predictable off-road handling in even the toughest conditions.
- Packed With 35 Years Of Race Winning Technology
- Performance Tuned For Vehicle Specific Application
- Aluminum Body Dissipates Heat Faster Than Steel
- IFP Separates Oil From High-Pressure Nitrogen Gas
- Black Anodized CNC Machined Aluminum Components
- FOX Racing Oil Developed For Ultimate Performance
- Large Heavy-Duty Hard Chrome 5/8 Inch Shaft
- Hour Glass Bushings Allow Increased Articulation
Information:
Increase your vehicle s off-road capability by extending drop-out travel in most applications. Experience on-road comfort with performance-minded shock valving for a connected ride with less vehicle sway. Tuned specifically for your vehicle s application._x000D__x000D_Consistent and fade-resistant performance due to high-quality materials: aluminum bodies; race-developed main piston; and a true internal floating piston (IFP) to separate gas and oil._x000D__x000D_Built-to-last; torture-tested and race-proven to give a lifetime of great rides. FOX products are built from aluminum; dissipating heat four times better than conventional materials. All FOX shocks are fully serviceable and resistant to corrosion and harsh environments.
Application Summary:
| Year |
Make/Model |
| 1994-2001 |
Dodge Ram 1500 |
| 2006-2008 |
Dodge Ram 1500 |
| 1994-2010 |
Dodge Ram 2500 |
| 1994-2010 |
Dodge Ram 3500 |
| 2011-2013 |
Ram 2500 |
| 2011-2012 |
Ram 3500 |
| Attributes |
| BM P/N |
213-28-001-B |
| Body Material |
Aluminum |
| Bottom Mount |
ES7 |
| Bottom Mount (P/N) |
213-28-001-B |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Collapsed Length |
15.200 in. |
| Collapsed Length (in.) |
15.200 |
| Color |
Aluminum |
| Country of Origin (Primary) |
US |
| Emission Code |
Legal US |
| Extended Length |
24.800 in. |
| Extended Length (in.) |
24.800 in. |
| FOX CATALOG |
TRUCK |
| GTIN |
00714686856836 |
| Harmonized Tariff Code (Schedule B) |
8708800050 |
| Hazardous Material Code |
N |
| Life Cycle Status Code |
Available to Order |
| NAFTA Preference Criterion Code |
B |
| Reservoir Type |
Remote |
| SDR Required Flag |
N |
| Series |
Performance |
| Shock Stroke |
9.600 in. |
| Shock Stroke (in.) |
9.600 |
| Size |
2 in. |
| TM P/N |
803-00-701 |
| Top Mount |
SM3 |
| Top Mount (P/N) |
803-00-701 |
| Type |
Smooth Body Shock |
| Warranty Time |
12 |
