Application specific valving to maximize performance.
Developed from our off-road race shocks, FOX Factory Race Series combines race-proven technology with new, cutting-edge features to provide enhanced ride-quality and winning damping performance you can bolt onto your truck or SUV.
- Performance Tuned For Vehicle Specific Application
- Durable Zinc Plated Seamless Alloy Body
- External Reservoir System Dissipates Heat Fast
- Black Anodized CNC Machined Aluminum Components
- 100% Serviceable And Tunable For Longer Lifespan
- Teflon-Lined Heat-Treated Spherical Bearings
- Redundant Sealing System/Long Lasting Performance
Information:
Uncompromised performance through FOX s patented internal bypass technology delivers the feel of near-endless suspension travel. Exclusive internal bypass technology allows oil to flow around the piston at some points of the stroke - while creating humongous pressure at other points - supporting the vehicle like no other product can.Floating through terrain is accomplished with FOX s ride zone - combining a race-developed shock piston; internal bypass and Dual Speed Compression adjustment - allowing fine tuning for weight; terrain and speed.Dominate any terrain with the brute strength of 3-and 2.5-in. aluminum bodies; cactus cooler reservoirs and 7/8in. shafts with redundant seals; all proven in the harshest of environments under the toughest of conditions.
Application Summary:
| Year |
Make/Model |
| 2012-2017 |
Ford Ranger |
| Attributes |
| Adjuster Type |
DSC - Dual Speed Compression |
| BM P/N |
213-27-000-B |
| Body Material |
Steel |
| Bottom Mount |
ES1 |
| Bottom Mount (P/N) |
213-27-003-B |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Collapsed Length |
15.710 in. |
| Collapsed Length (in.) |
15.710 |
| Color |
Steel |
| Country of Origin (Primary) |
US |
| Emission Code |
Legal US |
| Extended Length |
24.680 in. |
| Extended Length (in.) |
24.680 in. |
| FOX CATALOG |
TRUCK |
| GTIN |
00714686852579 |
| Harmonized Tariff Code (Schedule B) |
8708800050 |
| Hazardous Material Code |
N |
| Life Cycle Status Code |
Available to Order |
| NAFTA Preference Criterion Code |
B |
| Reservoir Type |
Piggyback |
| SDR Required Flag |
N |
| Series |
Factory Race |
| Shock Stroke |
8.970 in. |
| Shock Stroke (in.) |
8.97 |
| Size |
2.5 in. |
| TM P/N |
014-11-025 |
| Top Mount |
Eyelet |
| Top Mount (P/N) |
014-11-025 |
| Type |
Smooth Body Shock |
| Warranty Time |
12 |
