Fits 1957-1974 Corvette, Universal Center Dump, 327/350, V8, Shorty Headers, 1-5/8" Primary, 16 Gauge Tubing, 3/8" Flange, Silver Ceramic Coating, CARB EO D-698, 409S Stainless Steel
Flowmaster's Scavenger Series Elite shorty headers are designed to replace restrictive factory cast iron manifolds. These high quality headers are manufactured from stainless steel and are ceramic coated for maximum durability. They feature 1-5/8 in. primary tubes & 3/8 in. thick laser cut flanges. Like all Flowmaster products, the benefits include improved throttle response, power and engine efficiency. Designed for an easy fit, these headers include gaskets and necessary hardware for easy installation. Note 1 - some Corvette applications may require additional alternator mounting brackets. Note 2 - fits applications without air injection only. Note 3 - this product has been granted a California Air Resources Board (CARB) exemption, an E.O. number, or is a direct or consolidated replacement part. It is 50-state legal, per the application guide. CARB EO# D-698.
- 3/8-in. Thick Laser Cut Flanges
- Dyno tuned for maximum performance
- High Temperature Ceramic Coating
- Stainless Steel Construction
Information:
Fits 1957 to 1974 Corvette, with a 327 or 350 cubic inch displacement V8 engine, shorty headers, Universal Center Dump
Application Summary:
| Year |
Make/Model |
| 1957-1974 |
Chevrolet Corvette |
| Attributes |
| Application |
Automotive |
| Attachment Method |
Ball and Socket Flange, Ball & Socket Flange |
| Automotive Item Grade |
High Performance Part, High Performance |
| Bolt size |
3/8-16 x 1 |
| Bolts Or Studs Included |
Yes |
| Bolts/Studs Included |
Yes |
| Brand |
Flowmaster |
| Bullet Point #1 |
Stainless Steel Construction |
| Bullet Point #2 |
High Temperature Ceramic Coating |
| Bullet Point #3 |
Dyno tuned for maximum performance |
| Bullet Point #4 |
3/8in. Thick Laser Cut Flanges |
| C.A.R.B EO # |
D-698 |
| CARB (California) Compliant |
Yes |
| CARB EO# |
D-698 |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Category |
Exhaust |
| Clamping Type |
Round Band |
| Coated Finish |
Ceramic Coated Stainless Steel |
| Coating/Finish |
Ceramic Coated Stainless Steel |
| Collector Included |
Yes |
| Collector Tube Size |
N/A |
| Collector Tube Size (in.) |
N/A |
| Color |
Silver Ceramic |
| Color/Finish |
Silver Ceramic |
| Country of Origin (Primary) |
MX |
| Emission Code |
1, Legal US |
| Engine |
Chevrolet Small Block Gen I |
| Engine Make/Size |
Chevy 327/350 |
| Finish |
Silver Ceramic |
| Flange Thickness |
0.375 in., 3/8 |
| GTIN |
00700042026302 |
| Harmonized Tariff Code (Schedule B) |
8708925000 |
| Hazardous Material Code |
N |
| Head Style |
Block Hugger |
| Header Finish |
Silver Ceramic, Ceramic Coated |
| Header Flange Thickness |
3/8 inch |
| Header Flange Thickness (in) |
0.375, 3/8 inch |
| Header Series |
Scavenger Series Elite |
| Header Style |
Block Hugger |
| Inlet Port Shape |
Round |
| Life Cycle Status Code |
Available to Order |
| Main Piping Diameter |
1-5/8, 1.625 |
| Material |
Stainless Steel |
| NAFTA Preference Criterion Code |
B |
| Outlet Diameter |
2.500 in., 2.50 |
| Outlet Diameter (in) |
2.5 |
| Port Shape |
Same As Port/Can Be Matched |
| Port Size |
1.35" x 1.72" |
| Primary Tube Dia. |
1-5/8 inch |
| Primary Tube Diameter |
1.625 in. |
| Primary Tube Diameter (in) |
1.625 |
| Primary Tubing Diameter |
1-5/8" |
| Product Type |
Exhaust Headers, Headers |
| Reducers Included |
No |
| SDR Required Flag |
N |
| SDS Sheet Number |
N |
| SEMA Emissions Code |
3 |
| Series |
Scavenger Series Headers |
| Sub Category |
Exhaust Manifolds |
| Subcategory |
Headers and Parts |
| Tube Diameter |
1.625 in. |
| Tube Direction |
Up Swept |
| Tube Gauge |
16 |
| Tube Length |
Unequal Length |
| Tube Lengths |
Unequal Length |
| Tube Size |
1.625 |
| Tube Wall Thickness |
16 |
| Warning |
California Proposition 65 |
| Warranty Time |
12 |
| part type |
Exhaust Header |
