Fits Nissan Titan 2017-2024 trucks with the 5.6L engine. CARB EO #D-698-12 Compliant for 2017-2020 Titan with 5.6L.
This Flowmaster Delta Force Performance Air Intake system is for the 2017-2024 Nissan Titan with the 5.6L engine. The Delta Force® system contains a custom molded black Cross-Linked Polyethylene (XLPE) high-flow intake tube to maximize air flow, black anodized aluminum fittings (when applicable), high quality reinforced silicone couplers and all stainless steel hardware. Other features include a large diameter high-flow conical shaped 8 layer cotton gauze air filter, which traps more dirt than typical 6 layer designs, a custom-fit black powder-coated air dam with attachment brackets to securely mount the system in place along with soft bumpers to eliminate any metal to metal contact under the hood. The Delta Force Air Filters are serviceable with our Delta Force cleaning kits, #615001, which will help make your filter outlast your vehicle. This systems includes an easy bolt-on installation with no cutting or drilling. The Delta Force filters have a lifetime limited warranty and deliver power gains of up to 6% HP and TQ, with no tuning required. This kit is CARB Compliant under EO # D-698-12 for 2017-2020 Nissan Titan trucks with the 5.6L engine.
- Serviceable Lifetime High-Flow 8 Layer Cotton Gauze Filter
- No Special Tuning Required
- Lifetime Limited Warranty
- Flowmaster Quality
- Easy Installation
- Cross-Linked Polyethylene (XLPE) High-flow Intake Tube
- Serviceable with our Delta Force Cleaning Kit
- High Quality Components With Custom Look
- No Cutting or Drilling For Easy Installation
- Includes Stainless Steel Hardware
- Gains of up to 6% for HP and TQ
Information:
Does NOT fit XD Models or applications with a body lift.
Application Summary:
| Year |
Make/Model |
| 2017-2024 |
Nissan TITAN |
| Attributes |
| Air Box Included |
No |
| Air Filter Element Color |
Red, Red |
| Air Filter Element Material |
Oiled Cotton, Cotton Gauze |
| Air Filter Element Washable |
Yes, Yes |
| Air Filter End Cap Color/Finish |
Black, Black |
| Air Filter Heat Shield Color/Finish |
Black/Powder Coated, Black/Powder Coated |
| Air Filter Heat Shield Included |
Yes, Yes |
| Air Filter Heat Shield Material |
Steel, Steel |
| Air Filter Inside Diameter |
6, 6.00 |
| Air Filter Inside Diameter (in) |
6 |
| Air Filter Large End Diameter |
7.5, 7.50 |
| Air Filter Large End Diameter (in) |
7.5 |
| Air Filter Oil Included |
Pre-Oiled, Pre-Oiled |
| Air Filter Outlet Length |
1, 1 |
| Air Filter Outlet Length (in) |
1 |
| Air Filter Outlet Shape |
Circular, Circular |
| Air Filter Outlet Width |
6, 6.00 |
| Air Filter Outlet Width (in) |
6 |
| Air Filter Outside Diameter |
7.5, 7.50 |
| Air Filter Outside Diameter (in) |
7.5 |
| Air Filter Overall Height |
7.5, 7.50 |
| Air Filter Overall Height (in) |
7.5 |
| Air Filter Overall Length |
7.5, 7.50 |
| Air Filter Overall Length (in) |
7.5 |
| Air Filter Overall Width |
7.5, 7.50 |
| Air Filter Overall Width (in) |
7.5 |
| Air Filter Small End Diameter |
5, 5.00 |
| Air Filter Small End Diameter (in) |
5 |
| Brand |
Flowmaster, Flowmaster |
| CARB (California) Compliant |
Yes, Yes |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Category |
Air Intakes, Air and Fuel Delivery |
| Clamp Color/Finish |
Natural, Natural |
| Clamp Material |
Stainless Steel, Stainless Steel |
| Clamp Quantity Included |
4, 4 |
| Clamp Type |
Worm Gear, Worm Gear |
| Country of Origin (Primary) |
US |
| Coupler Color |
Black |
| Coupler Color/Finish |
Black, Black |
| Coupler Material |
Silicone |
| Coupler Quantity Included |
2, 2 |
| Emission Code |
7, 7, Not in CA |
| Filter Color |
Red |
| Filter Material |
Cotton Gauze |
| Filter Shape |
Cone |
| Fitment |
Direct Fit, Direct Fit |
| Fuel Type |
Gas, Gas |
| GTIN |
00700042039470 |
| Grade Type |
Performance |
| Harmonized Tariff Code (Schedule B) |
8421310000 |
| Hazardous Material Code |
N |
| Heat Shield Included |
Yes |
| Hose Color |
Black |
| Hose Material |
Polyethelene |
| Intake Pipe Color/Finish |
Black, Black |
| Intake Pipe Inlet Length |
1, 1 |
| Intake Pipe Inlet Length (in) |
1 |
| Intake Pipe Inlet Width |
3.6, 3.60 |
| Intake Pipe Inlet Width (in) |
3.6 |
| Intake Pipe Material |
Cross-Linked Polythylene, Cross-Linked Polyethylene |
| Intake Pipe Outlet Length |
1, 1 |
| Intake Pipe Outlet Length (in) |
1 |
| Intake Pipe Outlet Shape |
Round, Round |
| Intake Pipe Outlet Width |
3.1, 3.10 |
| Intake Pipe Outlet Width (in) |
3.1 |
| Intake Pipe Ports |
intake air temp. sensor, 3 |
| IntakePipe Inlet Shape |
Round, Round |
| Life Cycle Status Code |
Available to Order |
| MAF Sensor Adapter Included |
No, No |
| Mass Air Flow Sensor Included |
No, No |
| Mounting Hardware Included |
Yes |
| NAFTA Preference Criterion Code |
B |
| Product Type |
Performance Air Intakes, Performance Air Intakes |
| Replacement Filter PN (Dry) |
615011D |
| Replacement Filter PN (Oiled) |
615011, 615011 |
| SDR Required Flag |
N |
| Series |
Delta Force Air Intake Systems |
| Special Fitment Info |
Direct Fit, Direct Fit |
| Sub Category |
Fuel Injection System and Related Components, Fuel Injection System and Related Components |
| Subcategory |
Air Intake Systems |
| Tube Color |
Black |
| Tube Material |
PE (Polyethylene) |
| Vacuum Tubing Included |
No, No |
| Warning |
California Proposition 65, California Proposition 65 |
| part type |
Engine Cold Air Intake, Engine Cold Air Intake |
