Alcohol Race Muffler - 3.50 Offset In / 3.00 Same Side Out - Aggressive Sound
Alcohol race mufflers incorporate strategically placed "burn holes" inside the muffler in all of the low-pressure areas to prevent damage from excess methanol fuel from puddling and backfiring on deceleration. Through years of racing and partnerships with leading race sanctioning bodies, Flowmaster has developed these specialty mufflers that have been specifically engineered for race vehicles in organizations such as NASCAR, ARCA, and the W.O.O. sprint car series. These include race mufflers for low ground clearance, special race fuels, packaging restraints, etc.
- Race proven Delta Flow technology
- No internal packing to blowout
- Good decibel reduction over open headers
- Durable fully welded 16 gauge aluminized steel - two chamber race muffler
Information:
Universal Race Muffler - Not a direct fit. Some adaptation required.
Application Summary:
| Year |
Make/Model |
| Universal |
Race Muffler - Not a direct fit. Some adaptation required. |
| Attributes |
| ASIN |
B000NDTCXK |
| Automotive Item Grade |
High Performance |
| Body Diameter (in) |
12 |
| Body Height |
5.000 in. |
| Body Height (in) |
5 |
| Body Height (in.) |
5 |
| Body Length |
13.500 in. |
| Body Length (in) |
13.5 |
| Body Length (in.) |
13.5 |
| Body Width |
10.000 in. |
| Body Width (in) |
10 |
| Body Width (in.) |
10 |
| Brand |
Flowmaster |
| Bullet Point #1 |
Durable fully welded 16 gauge aluminized steel - two chamber race muffler |
| Bullet Point #2 |
Good decibel reduction over open headers |
| Bullet Point #3 |
No internal packing to blowout |
| Bullet Point #4 |
Race proven patented Delta Flow technology |
| California Proposition 65 |
No |
| Category |
Exhaust |
| Color |
Black |
| Country of Origin (Primary) |
CN |
| Emission Code |
5 |
| Fitment |
Universal |
| GTIN |
00700042012671 |
| Harmonized Tariff Code (Schedule B) |
8708925000 |
| Hazardous Material Code |
N |
| Inlet |
3-1/2 Offset |
| Inlet Connection Type |
Pipe, Pipe Connection |
| Inlet Diameter |
3.500 in., 3.50 |
| Inlet Diameter (in) |
3.5 |
| Inlet Inside Diameter |
3.500 in. |
| Inlet Inside Diameter (in.) |
3.5 |
| Inlet Outside Diameter |
3.500 in. |
| Inlet Position |
Offset |
| Inlet Size (in.) |
3.5 |
| Inlet Type |
Single Offset |
| Life Cycle Status Code |
Available to Order |
| Main Piping Diameter |
OEM |
| Main Piping Diameter (in.) |
OEM |
| Material |
Aluminized Steel |
| Mount Type |
Uses New Hangers (Not Included) |
| Muffler Count |
1 |
| Muffler Series |
40 Series Delta Force |
| Muffler Type |
Reflection |
| NAFTA Preference Criterion Code |
B |
| Outlet |
3 inch offset |
| Outlet Connection Type |
Pipe, Pipe Connection |
| Outlet Diameter |
3.000 in. |
| Outlet Diameter (in) |
3 |
| Outlet Inside Diameter |
3.00 |
| Outlet Location |
Offset (Same Side) |
| Outlet Outside Diameter |
3.000 in., 3.13 |
| Outlet Outside Diameter (in.) |
3 |
| Outlet Position |
Same Side, Offset (Same Side) |
| Outlet Size (in.) |
3 |
| Outlet Type |
Single Offset Outlet |
| Overall Length |
22.000 in. |
| Overall Length (in) |
22 |
| Overall Length (in.) |
22.000 in. |
| Position |
N/A |
| Product Type |
Race Products |
| SDR Required Flag |
N |
| SDS Sheet Number |
N |
| Series |
40 Series Delta Force Mufflers |
| Shape |
Oval |
| Sound Level |
Aggressive, Aggressive Sound |
| Sub Category |
Mufflers |
| Subcategory |
Mufflers |
| Type of Muffler |
Chambered |
| Vehicle Type |
Race |
| Warranty Time |
12 |
| part type |
Exhaust Muffler |
