CURT 60614 Factory Original Equipment Style Gooseneck Hitch, 30,000 lbs. 2-5/16-Inch Ball, Fits Select Ram 2500
CURT OEM-style gooseneck hitches are built for specific pickup trucks to tackle big jobs. OEM-style hitches are unique because they do not require additional installation brackets. They bolt directly onto the vehicle's frame and use pre-existing bolt holes to install in 45 minutes or less. They also require no welding, bed flange trimming or bed removal. This particular hitch is designed to fit specific years of the Ram 2500. Each OEM-style Ram hitch comes with a factory-style gooseneck ball and all the necessary hardware for a complete installation. This Ram OE gooseneck hitch offers a gross trailer weight capacity of 30,000 lbs. and a vertical load limit of 7,500 lbs. It is perfect for towing everything from farm animals in your livestock trailer to industrial materials on a flatbed (limited to lowest rated towing component). It comes with a patented 2-5/16" gooseneck trailer ball that can be installed and removed easily with a simple quarter-turn of the integrated lever. To ensure that this Ram gooseneck hitch has what it takes to keep up with you and your truck, it also comes with an A-coat finish for excellent rust resistance. It has heavy-duty 5/8" safety chain anchors for a reliable backup connection.
- Up to 30,000 lbs. GTW and 7,500 lbs. vertical load
Information:
Up to 30,000 lbs. GTW and 7,500 lbs. vertical load
Application Summary:
| Year |
Make/Model |
| 2014-2018 |
Ram 2500 |
| Attributes |
| ASIN |
B00IISUW04 |
| Ball Diameter |
2-5/16 IN, 2.3125 in. |
| Ball Diameter (in.) |
2.3125 |
| California Proposition 65 |
Yes |
| Container Volume Cubic Feet - XA |
0.00000 |
| Container Volume Cubic Meter - XA |
0.00000 |
| Country of Origin (Primary) |
US |
| Drilling Required |
No |
| Finish |
Carbide Black Powder Coat |
| Finish - XA |
A-COAT, A-COAT |
| GTIN |
00612314606146 |
| Gooseneck Hitch Type |
OEM Compatible, OEM Compatible |
| Gross Trailer Weight |
30000 lbs. |
| Gross Trailer Weight (GTW) |
30,000 LB, 30,000 LB |
| Gross Trailer Weight (lbs.) |
30000 |
| Gross Trailer Weight(GTW) |
30,000 LB |
| Harmonized Tariff Code (Schedule B) |
8708998180 |
| Hazardous Material Code |
N |
| Install Time |
45 Minutes |
| Item Class - XA |
OMF, OMF |
| Item Height - XA |
4.380, 4.380 |
| Item Length - XA |
18.000, 18.000 |
| Item Width - XA |
9.940, 9.940 |
| Life Cycle Status Code |
Available to Order |
| Long Description |
Gooseneck Hitch |
| Master Case Height Inches - XA |
0.000 |
| Master Case Length Inches - XA |
0.000 |
| Master Case Volume Cubic Feet - XA |
0.00000 |
| Master Case Weight Lbs - XA |
0.000 |
| Master Case Width Inches - XA |
0.000 |
| Material - XA |
Carbon Steel |
| Mount Type Description - XA |
Blank |
| NAFTA Preference Criterion Code |
B |
| Pallet Qty - XA |
40.000 |
| Pallet Total Height Inches - XA |
0.000, 0.000 |
| Pallet Total Weight Per - XA |
0.000, 0.000 |
| Parcel Allowed - XA |
Yes, Yes |
| Product Weight - XA |
49.600, 49.600 |
| Rate Class - XA |
70.0, 77.5 |
| Retail Height - XA |
7.250, 7.250 |
| Retail Length - XA |
21.250, 21.250 |
| Retail Width - XA |
11.250, 11.250 |
| SDR Required Flag |
N |
| Sales Family Code - XA |
GOOSE, GOOSE |
| Sales Family Description - XA |
GOOSENECK, GOOSENECK |
| Sales Group Description - XA |
GOOSENECK HITCH, GOOSENECK HITCH |
| Shipping Weight - XA |
50.600, 50.600 |
| Side Application Type Description - XA |
Blank, Blank |
| Tariff 301 - XA |
No, No |
| Tongue Weight (TW) |
7,500 LB, 7,500 LB |
| Tongue Weight(TW) |
7,500 LB |
| Truckload Volume Cubic Feet - XA |
0.00000, 0.00000 |
| Vertical Load |
7,500 LB, 7500 |
| WC Tongue Weight |
7500 |
| Warranty |
Limited Lifetime Warranty (One-Year Finish, One-Year Parts), Limited Lifetime Warranty (One-Year Finish, One-Year Parts) |
