CURT 58901 Custom Towed-Vehicle RV Wiring Harness for Dinghy Towing; Fits Select Honda CR-V
Towing your vehicle behind your RV is a great way to experience more of the adventure on your cross-country excursions. Whether youre towing a compact car or a full-size truck, CURT has the perfect solution to help you Bring It! CURT towed-vehicle RV harnesses are a vehicle-specific, plug-and-play solution to wiring your vehicle for dinghy towing. They use original-equipment-compatible connectors to plug into your vehicles wiring system without any cutting, splicing or soldering required. They provide a standard 4-way flat connector to plug into the RV socket and synchronize the vehicles tail lights, turn signals and brake lights with the RVs. Because each towed-vehicle RV harness has a vehicle-specific design, installation is fast and easy. This particular RV dinghy towing wiring harness is designed for specific years of the Honda CR-V. CURT RV harnesses are also built to provide long-lasting operation. They feature integrated block diodes that protect the vehicles circuits from the RV signals. They isolate the sensitive vehicle electronics, keeping them from overheating and short circuiting. Every CURT towed-vehicle RV harness comes ready to install with all necessary hardware included. They also come with a 4-way flat extension to provide plenty of length to plug into the RV socket, as well as a connector mounting bracket to mount the connector on the vehicle.
  • Connects A Towed Vehicle To An Rv Using A Standard 4-Way Flat
  • Simple Plug-And-Play Design Eliminates The Need For Splicing
  • Diodes Isolate Sensitive Vehicle Electronics From RV Signal
  • Uses VehicleS Existing Taillights; Brake Lights And Turn Signals

Information:

Connects a towed vehicle to an RV using a standard 4-way flat trailer plug; Simple plug-and-play design eliminates the need for cutting or splicing; Integrated block diodes isolate sensitive vehicle electronics from RV signals; Uses towed vehicle's existing taillights, brake lights and turn signals; Custom Towed-Vehicle RV Wiring Harness, Select Honda CR-V

Application Summary:

Year Make/Model
2007-2011 Honda CR-V
Attributes
ASIN B074RN9LRT
Box Height in Inches - XA 2, 6
Box Length in Inches - XA 7, 9
Box Width in Inches - XA 4, 8
California Proposition 65 WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Class ID 11
Container Volume Cubic Feet - XA 0.00000
Container Volume Cubic Meter - XA 0.00000
Country of Origin (Primary) MX
Emission Code Legal US
Finish - XA N/A
GTIN 00612314039401
Harmonized Tariff Code (Schedule B) 8544300000
Hazardous Material Code N
Item Class - XA CME
Item Height - XA 0.000, 4.500
Item Length - XA 0.000, 8.500
Item Width - XA 0.000, 8.500
Life Cycle Status Code Available to Order
Master Case Height Inches - XA 14.000
Master Case Length Inches - XA 17.000
Master Case Qty - XA 12
Master Case Volume Cubic Feet - XA 0.00000
Master Case Weight Lbs - XA 25.000
Master Case Width Inches - XA 17.000
Material - XA Blank
Mount Type Description - XA Blank
NAFTA Preference Criterion Code B
Pallet Case Per - XA 12
Pallet Case Per Layer - XA 6
Pallet Cases Per - XA 12
Pallet Cases Per Layer - XA 6
Pallet Layer of Cases - XA 2
Pallet Total Height Inches - XA 40.125
Pallet Total Weight Per - XA 340.000
Parcel Allowed - XA Yes
Price Code - XA E21
Product Weight - XA 0.000, 2.000
Rate Class - XA 70.0
Retail Height - XA 4.500
Retail Length - XA 8.500
Retail Width - XA 8.500
SDR Required Flag N
Sales Family Code - XA ELECT
Sales Family Description - XA ELECTRICAL COMPONENTS
Sales Group Description - XA RV HARNESS
Shipping Weight - XA 2.000
Side Application Type Description - XA Blank
T-Connector Location S3,S4
Tariff 301 - XA No
Truckload Volume Cubic Feet - XA 0.00000
Warranty One-Year Limited Warranty
