CURT 57003 LED-Compatible 7-Way RV Blade Vehicle-Side Trailer Wiring Adapter

---

There are several different types of connectors used to supply power from a tow vehicles electrical system to a trailers wiring system. Some trailers only need the bare essentials -- running lights, brake lights and turn signals -- while others require a connection for reverse lights, electric brakes and auxiliary power. With connectors ranging from simple to complex, it may be the case that the connection between your vehicle and your trailer is not a perfect match. For example, your truck may be equipped with a 6-way round socket, but your trailer may have a 4-way flat plug. For this very common problem, CURT offers a quick and simple solution in the form of an electrical adapter. An adapter is an electrical device that allows a connection to be made between a mismatched trailer plug and vehicle socket. It easily plugs in your vehicles electrical socket and usually requires no additional wiring. CURT offers an array of adapters to accommodate most types of plugs and sockets, including 4-way flat, 4-way round, 5-way flat, 6-way round, 7-way RV blades and more. This special trailer light adapter is designed to plug into an existing 7-way RV blade socket to allow the vehicle to recognize LED trailer lights. It features built-in resistors for vehicles with computers that dont recognize LED lights and enables them to be compatible with trailers that have them. It is not intended to be used as a wiring extension. This 7-way RV blade adapter requires no splicing and is a custom wiring option for certain years of the Porsche Cayenne, Audi Q7 Quattro or Volkswagen Touareg or VW Colorado (to verify your vehicle compatibility, see the CURT application guide at curtmfg.com). All CURT wiring and electrical products come with a one-year limited warranty to give you the assurance you need to tow with confidence.

• Enables 7-Way Rave Blade Socket To Recognize Led Trailer Lights
• Integrated Resistor For Computers That Dont Recognize Led Lights
• 7-Way Connects Tail Brake Reverse Turn Signals Brakes
• Simple Plug-And-Play Design Eliminates The Need For Splicing
• Spring-Loaded Dust Cover Keeps Connector Clean When Not In Use

---

Information:

7-Way RV Blade LED Electrical Adapter (Not a Wiring Extension); Enables vehicles with a 7-way RV blade socket to recognize LED trailer lights; Built-in, integrated resistors for computers that don't recognize LED lights; 7-way connects tail, brake, reverse, turn signals, brakes and auxiliary power; Simple plug-and-play design eliminates the need for cutting or splicing; Spring-loaded dust cover keeps connector clean when not in use

---

Application Summary:

Year	Make/Model
2007-2012	Audi Q7
2004-2006	Porsche Cayenne
2008-2012	Porsche Cayenne
2004-2012	Volkswagen Touareg
