CURT 14081 Class 4 Trailer Hitch, 2-Inch Receiver, Fits Select Chevrolet, GMC C/K Pickup Trucks
Whatever the next item is on your to-do list -- whether it's arriving at the jobsite before dawn or getting your travel trailer set up in time to see the sunset -- CURT class 4 trailer hitches offer greater towing power to let you Bring It. These custom receiver hitches are built to tackle bigger jobs and bolder adventures, all while giving you a custom fit for your vehicle. Class 4 hitches are available for a variety of makes and models, from pickup trucks and SUVs to full-size and commercial vans. This particular class 4 hitch fits certain years of the Chevy or GMC C1500, C2500, C3500, K1500, K2500, K3500, Silverado / Sierra 1500 and 2500 (to verify vehicle compatibility, see application info). It provides a weight carrying capacity of 10,000 lbs. GTW and 1,000 lbs. TW. It can also accept a weight distributing hitch, offering a maximum WD capacity of 12,000 lbs. and a WDTW of 1,200 lbs. CURT class 4 tow hitches are as much suited for work as they are for play. With their high load capacities, they are typically used for towing larger trailers, including everything from a double-axle utility trailer or livestock trailer to a full-length camper or large boat trailer (NOTE: Never exceed the lowest weight capacity of any towing component). All CURT class 4 receiver hitches come with a 2" receiver tube opening and all the necessary hardware for a complete installation. From light-duty to heavy-duty, every CURT custom hitch is engineered to be vehicle-specific, using actual vehicles to create the optimal design. We then combine high-strength steel, precise welding and a co-cured finish of liquid A-coat and durable black powder coat to provide you with a hitch you can depend on. To prove it, we test all our hitches in accordance with SAE J684 for safety.
- Made in USA (may include imported hardware)
- Protected by a durable high-gloss black powder coat finish
- Co-cured in a rust-resistant liquid A-coat, inside and out
- Equipped with an open-back receiver for easy cleaning
- Limited lifetime warranty (one-year finish, one-year parts)
- Rated to 10,000 lbs. gross trailer weight and 1,000 lbs. tongue weight
- Compatible with weight distribution hitch (12,000 lbs. WD / 1,200 lbs. WDTW)
- Engineered with a vehicle-specific design for a custom fit
- Concealed main body for OE look and seamless integration with the vehicle
- Tested for safety in accordance with SAE J684
- Precisely welded for superior strength and fit
Information:
Protected by a durable high-gloss black powder coat finish
Application Summary:
Year |
Make/Model |
1988-1999 |
Chevrolet C1500 |
1988-2000 |
Chevrolet C2500 |
1988-2000 |
Chevrolet C3500 |
1988-1999 |
Chevrolet K1500 |
1988-2000 |
Chevrolet K2500 |
1988-2000 |
Chevrolet K3500 |
1988-1999 |
GMC C1500 |
1988-2000 |
GMC C2500 |
1988-2000 |
GMC C3500 |
1988-1999 |
GMC K1500 |
1988-2000 |
GMC K2500 |
1988-2000 |
GMC K3500 |
Attributes |
ASIN |
B0009XG9KS |
Attachment Location |
Rear |
Body Shape |
Square |
Box Height in Inches - XA |
27, 27 |
Box Length in Inches - XA |
38, 38 |
Box Width in Inches - XA |
9, 9 |
California Proposition 65 |
Yes |
Class ID |
4, 4 |
Color |
Black |
Container Volume Cubic Feet - XA |
0.00000, 0.00000 |
Container Volume Cubic Meter - XA |
0.00000, 0.00000 |
Country of Origin (Primary) |
US |
Drilling Required |
No, No |
Finish |
Gloss Black Powder Coat, Powder Coated |
Finish - XA |
GLOSS BLACK POWDER COAT, GLOSS BLACK POWDER COAT |
GTIN |
00612314140817 |
Gross Trailer Weight |
10000 lbs. |
Gross Trailer Weight (lbs.) |
10000 |
Harmonized Tariff Code (Schedule B) |
8708998180 |
Hazardous Material Code |
N |
Hitch Class |
IV |
Install Time |
30 Minutes |
Item Class - XA |
MFH, MFH |
Item Height - XA |
7.810, 7.810 |
Item Length - XA |
37.230, 37.230 |
Item Width - XA |
27.180, 27.180 |
Life Cycle Status Code |
Available to Order |
Long Description |
Class IV Trailer Hitch |
Main Body Shape |
Square, Square |
Master Case Height Inches - XA |
0.000, 0.000 |
Master Case Length Inches - XA |
0.000, 0.000 |
Master Case Volume Cubic Feet - XA |
0.00000, 0.00000 |
Master Case Weight Lbs - XA |
0.000, 0.000 |
Master Case Width Inches - XA |
0.000, 0.000 |
Material - XA |
Carbon Steel, Carbon Steel |
Mount Type Description - XA |
Blank, Blank |
Mounting Hardware Included |
Yes |
NAFTA Preference Criterion Code |
B |
Pallet Qty - XA |
18.000, 18.000 |
Pallet Total Height Inches - XA |
0.000, 0.000 |
Pallet Total Weight Per - XA |
0.000, 0.000 |
Parcel Allowed - XA |
Yes, Yes |
Position |
Rear |
Price Code - XA |
59, 59 |
Product Weight - XA |
47.000, 47.000 |
Rate Class - XA |
70.0, 125.0 |
Receiver Included |
No |
Receiver Size |
2 |
Receiver Tube Size |
2 IN, 2.000 in. |
Retail Height - XA |
10.000, 10.000 |
Retail Length - XA |
39.000, 39.000 |
Retail Width - XA |
29.000, 29.000 |
SDR Required Flag |
N |
Sales Family Code - XA |
HITCH, HITCH |
Sales Family Description - XA |
HITCH, HITCH |
Sales Group Description - XA |
CL 4, CL 4 |
Shipping Weight - XA |
54.000, 54.000 |
Side Application Type Description - XA |
Blank, Blank |
Tariff 301 - XA |
No, No |
Tongue Weight (TW) |
1,000 LB, 1,000 LB |
Tongue Weight(TW) |
1,000 LB |
Truckload Volume Cubic Feet - XA |
0.00000, 0.00000 |
Visibility |
Concealed |
WC Tongue Weight |
1000 |
WD Tongue Weight |
1200 |
Warranty |
Limited Lifetime Warranty (One-Year Finish, One-Year Parts), Limited Lifetime Warranty (One-Year Finish, One-Year Parts) |
Weight Carrying Capacity |
10000 |
Weight Carrying Capacity (WC) |
10,000 LB, 10,000 LB |
Weight Carrying Capacity(WC) |
10,000 LB |
Weight Distribution |
12000 |
Weight Distribution (WD) |
12,000 LB, 12,000 LB |
Weight Distribution Tongue Weight (WDTW) |
1,200 LB, 1,200 LB |
Weight Distribution Tongue Weight(WDTW) |
1,200 LB |
Weight Distribution(WD) |
12,000 LB |
