CURT 13190 Class 3 Trailer Hitch, 2-Inch Receiver, Fits Select Mercedes-Benz GL450, GL550, GLS450, GLS550
Whatever your task at hand -- whether it's launching that boat before daybreak, setting up your camper before the rush or getting a final load to the dump before close -- CURT class 3 trailer hitches offer the strength needed for serious towing. They make it easy to hitch up and Bring It, offering a vehicle-specific fit and the weight capacity to handle a variety of trailers. Custom class 3 hitches are the most common type of receiver hitch for pickup trucks and SUVs. Because of their weight range, they are also found on full-size cars, crossovers and minivans. Each custom-fit class 3 hitch package is made for vehicle-specific mounting. This particular kit fits certain years of the Mercedes-Benz GL450, GL550, GLS450 and GLS550 (see application info to verify vehicle compatibility). It provides a weight carrying capacity of 7,500 lbs. GTW and 900 lbs. TW. CURT class 3 trailer hitches are typically used to attach and haul utility trailers, boat trailers, campers, snowmobile or ATV haulers and more (NOTE: Never exceed the lowest-rated towing component). Each class 3 hitch has a 2" receiver tube and is tested in accordance with SAE J684 for safety. To ensure that CURT class 3 receiver hitches have what it takes for serious trailering, they are designed using a hands-on approach and are constructed with rugged, high-strength steel and precise welding. We also protect our class 3 hitches in a co-cured finish of liquid A-coat and black powder coat for superior resistance to rust, chipping and UV damage.
  • Co-cured in a rust-resistant liquid A-coat, inside and out

Information:

Rated to 7,500 lbs. gross trailer weight and 900 lbs. tongue weight

Application Summary:

Year Make/Model
2014-2016 Mercedes-Benz GL450
2014-2016 Mercedes-Benz GL550
2017-2019 Mercedes-Benz GLS450
2017-2019 Mercedes-Benz GLS550
Attributes
Body Shape Flat
Box Height in Inches - XA 12, 12
Box Length in Inches - XA 50, 50
Box Width in Inches - XA 19, 19
California Proposition 65 Yes
Class ID 3, 3
Container Volume Cubic Feet - XA 0.00000
Container Volume Cubic Meter - XA 0.00000
Country of Origin (Primary) US
Drilling Required No
Finish Gloss Black Powder Coat
Finish - XA GLOSS BLACK POWDER COAT, GLOSS BLACK POWDER COAT
GTIN 00612314131907
Gross Trailer Weight 7500 lbs.
Gross Trailer Weight (lbs.) 7500
Harmonized Tariff Code (Schedule B) 8708998180
Hazardous Material Code N
Install Time 40 Minutes
Item Class - XA MFH, MFH
Item Height - XA 8.220, 8.220
Item Length - XA 46.380, 46.380
Item Width - XA 10.000, 10.000
Life Cycle Status Code Available to Order
Long Description Class III Trailer Hitch
Main Body Shape Flat, Flat
Master Case Height Inches - XA 0.000
Master Case Length Inches - XA 0.000
Master Case Volume Cubic Feet - XA 0.00000
Master Case Weight Lbs - XA 0.000
Master Case Width Inches - XA 0.000
Material - XA Carbon Steel
Mount Type Description - XA Blank
NAFTA Preference Criterion Code B
Pallet Qty - XA 26.000
Pallet Total Height Inches - XA 0.000, 0.000
Pallet Total Weight Per - XA 0.000, 0.000
Parcel Allowed - XA Yes, Yes
Position Rear
Price Code - XA 101, 101
Product Weight - XA 66.000, 66.000
Rate Class - XA 70.0, 125.0
Receiver Tube Size 2 IN, 2.000 in.
Retail Height - XA 8.000, 8.000
Retail Length - XA 50.000, 50.000
Retail Width - XA 19.000, 19.000
SDR Required Flag N
Sales Family Code - XA HITCH, HITCH
Sales Family Description - XA HITCH, HITCH
Sales Group Description - XA CL 3, CL 3
Shipping Weight - XA 73.000, 73.000
Side Application Type Description - XA Blank, Blank
Tariff 301 - XA No, No
Tongue Weight (TW) 900 LB, 900 LB
Tongue Weight(TW) 900 LB
Truckload Volume Cubic Feet - XA 0.00000, 0.00000
Visibility Concealed
WC Tongue Weight 900
Warranty Limited Lifetime Warranty (One-Year Finish, One-Year Parts), Limited Lifetime Warranty (One-Year Finish, One-Year Parts)
Weight Carrying Capacity 7500
Weight Carrying Capacity (WC) 7,500 LB, 7,500 LB
Weight Carrying Capacity(WC) 7,500 LB
Weight Distribution (WD) n/a, n/a
Weight Distribution Tongue Weight (WDTW) n/a, n/a
Weight Distribution Tongue Weight(WDTW) n/a
Weight Distribution(WD) n/a
