Twisted Steel 304 Stainless Steel Race Series Performance Package Nissan Patrol (Y61) 01-16 L6-4.8L

---

Tri-Y Design: Paired opposite firing cylinders with equal, specifically tuned primary lengths maximizes scavenging and increases torque throughout the power band. 304 Stainless Steel Laser Cut Header Flanges: High quality laser cut 304 stainless steel header flanges provides superior sealing at the head surface. 304 Stainless Steel Tubing: High grade stainless tubing with a uniform brushed finish provides a beautiful look and high resistance to corrosion. TIG-Welded: 100% TIG-Welded by certified craftsmen for race proven strength and durability. TIG-Welding provides the strongest welds reducing stress cracks. Factory Mounting Locations: 2.5Inlet/Outlet Connection Pipe mount directly to OE mounting locations. Mandrel Bent Tubing: This system is constructed of mandrel bent, stainless steel brushed tubing for maximum performance, corrosion resistance and strength eliminating cracking. Emissions Disclaimer: This product does not require a CARB EO# (Vehicle does not exist in U.S.). aFe Twisted Steel Headers are engineered and manufactured in our Corona, California manufacturing facility.

• Fits 4-Door with Automatic & Manual Transmissions
• 1-3/4 Primary Tubing, 2-1/8 Secondary Tubes, & 2-1/2 Collector
• 6-2-1 Tri-Y Design
• 3/8 Thick 304 Stainless Steel Head Flanges
• Optimized Tube Lengths for Improved Flow
• Retains Factory O2 Sensor Locations
• 2-1/2 Inlet/Outlet Connection Pipe Mounts Directly to OE Mounting Locations

---

Application Summary:

Year	Make/Model
Nissan	Patrol (Y61) 01-16 L6-4.8L
